The Supertechno 30 is the standard for telescopic arms with a 23ft telescopic range (7ft - 30ft reach) and a 30ft lens height. It ncludes the speed box and 3-axis capable Z-HEAD and can support any other remote head, 3D-camera setup or heavy load without worry. This is the workhorse of the telescopic arms, equally capable outdoors, on a stage, or any location.

Our SuperTechno 30 is always configured to support 16mm & 35mm film cameras, professional video, digital video, and HD cameras. It can also work with large format cameras (65mm & IMAX). The Z Head, the standard remote head on Technocranes,  controls 3 axis of camera movement (pan, tilt, roll). For more info on all our camera cranes, click here.

SPECS

• Max. Lens Height: 30’
• Telescopic Range: 23’
• Max. Nose Load: 80 lbs.
• Clearance (Width x Height): 4’ 6” x 6’ 11”
• Arm Clearance Width: approx. 1’ (12”)
• Arm Clearance Height: 1’ 4” (16”)
• Min. Length (Post to Nose): 7’ 10”
• Max. Length (Post to Nose): 30’
• Overall Length Retracted: 16’
• Overall Length Extended: 38’
• Length Post to rear: 8’
• Arm Width: 4’ 3” (51”) Removable Side Handles
• Max. Crane Height: 8’ 7”
• Min. Crane Height: 6’ 11”
• Base Length: 5’ 6” (66”)
• Base Width: 4’ 6” (54”)
• Base Height: (floor to bottom of base) 4”
• Wheel Height: 18”
• Track Width: 4’ 9”
• Sleeper Width: 5’
• Z Head Length – Normal: 29”
• Z Head Length – Shortest: 17”
• Z Head Min. Dimensions: 17” x 16”
• Arm Weight: 760 lbs.
• Column Weight: 262 lbs.
• Dolly Weight: 710 lbs.
• Counterweights: 1,280 lbs.(42 weights @ 30 lbs. each, plus assorted smaller weights)
• Z Head: 43 lbs.
• Total Weight: 2,850 lbs. Telescope Speed: 0-6ft. / sec.
• Power: 120V / 20Amps
• Set up time: 1 hour
• Transported in Trailer

FEATURES

• 30ft Max reach and lens height
• Telescopic arm allows camera to move around objects without the need for track
• Telescopic speed: up to 10 ft/sec
• Video-style joystick operation available
• Lens control required
• 4'6" W x 6'11"H allows access through standard double doors
